Description

• Features:
• Integrated Charging-storage Energy System
  Reducing wiring
  It is convenient for users to operate, and greatly reducing the space occupancy rate
• Wide-voltage input, improve the degree of freedom of solar panel in series or parallel connection
  Will not be broken down, and greatly reduce the risk of the lithium battery’s thermal runaway burning
• Effectively track the maximum power point of the solar panel and increase the daily power generation of the solar panel by more than 30%
• Specifications:
• Storage Capacity: 2560Wh
• Standard Capacity: 100Ah/25.6V
• Continuous input current: 80A
• Continuous output current: 80A
• Standard charging voltage: 28.8V - 30V
• Cut off: 18V-24V
• Self-discharge (25°C): <3%-month
• Depth of discharge: >80%
• Operating temperature range: -20°C-70°C,
• Recommended temperature range: 10°C -45°C
• Cycle life: >5000 times (<0.5C)
• C-rate Discharge: <0.8C
