Description

Features:

• High-Performance Unidirectional Scanning
• Ultra High-speed Auto sensing (2600 fps)
• Dual LED Optimized Illumination Array
• LED Status Indicator, Audible Beeper
• Single USB Cable for Power and Data
• Plug & Play Driver less Operation Mode
• Multi-interface options (USB HID, VCOM, RS232)
• Compact Modern Design (145 x 85 x 105 mm)

Specification:

• Scan Engine: CMOS
• Aiming LED: 655nm Laser
• Illumination Element: 2x 625 nm LEDs
• Depth of field: 0-270 mm
• Scan Speed: 2600 frames per sec (FPS)
• Sensor: CMOS (1280 pixels H x 800 pixels V)
• Best resolution: ? 4 mil
• Reading angle: Yaw (Skew) 72 Pitch 82
• Print contrast: ? 30
• Indicators: LED status Indicator & Audible Beeper
• Interface: USB HID, USB Virtual COM Port, RS-232 (serial)
• Triggering: Auto-sensing & Manual Scan Button
• Input voltage: 5 VDC  0.5 V
• Current  operating: Operating 780 mA, Idle 255 mA
• Dimensions: 145 X 85 X 105 mm (L x W x H)
• Weight: 465 g +/- 5 g (Without cable)
• Operating temperature: -20? to 50?
• Storage temperature: -20? to 45?
• Humidity: 5% to 85% relative humidity, non-condensing
• Ambient Light: Maximum 96900 Lux. (direct sunlight)
